Warehouse Shelves Storage Racks Making Machine Reliable 1 Year Warranty Custom Production
‹ › When overseas customers buy a warehouse shelves storage racks making machine, they often face a common problem. Their factory voltage standard differs from the default machine configuration. The upright profile they need to produce also differs from the standard setup. A standard machine may not directly match every factory's actual conditions. Voltage, speed, profile,…
Contact: Elliot liu
Email: [email protected]
WhatsApp: 008615127728988
Detailed Content
When overseas customers buy a warehouse shelves storage racks making machine, they often face a common problem. Their factory voltage standard differs from the default machine configuration. The upright profile they need to produce also differs from the standard setup. A standard machine may not directly match every factory's actual conditions. Voltage, speed, profile, and thickness all need to be confirmed before purchase. This equipment supports custom voltage, control system language, and some production configurations. It also comes with a 1 year warranty and remote video guidance.
Applications
The rack uprights produced by this warehouse shelves storage racks making machine are the core load bearing parts in a rack system. They support the weight of the entire rack, connect with beams and braces, and form the critical frame of the rack.
This equipment produces two section sizes: 65×80 mm and 65×100 mm. A shelf pillar machine produces uprights used in pallet racks, heavy duty racks, and adjustable rack systems for warehouses and logistics centers.
A warehouse shelves storage racks making machine produces uprights that later go through welding, assembly, and installation at the warehouse site. The dimensional accuracy of the uprights affects the installation efficiency of the rack system.
Machine Advantages
-
Working voltage can be customized to the customer's local standard to match electrical conditions in different countries and regions.
-
The control system language supports Chinese and English, and other languages can be customized on request.
-
Production profiles can be customized to the customer's product drawings.
-
One machine can produce two specifications, and switching is done by setting parameters on the PLC.
-
The machine can be adjusted at the factory to match customer conditions, reducing modification work after arrival.
A shelf uprights forming machine that only ships with a fixed configuration may need extra modification after arrival at an overseas factory. This machine can be adjusted at the factory to match customer conditions.
Warehouse Shelves Storage Racks Making Machine Technical Specifications
| Parameter | Value |
|---|---|
| Material | Low carbon steel, galvanized steel, hot rolled or cold rolled |
| Thickness | 2.0 to 2.5 mm |
| Forming speed | Above 20 m per minute |
| Main motor power | 11 kW x 2 sets |
| Hydraulic power | 11 kW |
| Working voltage | 380V 50Hz 3 phase or on request |
| Decoiler capacity | 5 t |
| Leveling rollers | 7 rollers, 3 top and 4 bottom |
| Roller material | Gcr12 quenched |
| Shaft material | 45# steel tempered |
| Number of rollers | 20 forming rollers |
| Punching press | 80 t pneumatic |
| Cutting method | Servo tracking shear |
| Section sizes | 65×80 mm, 65×100 mm |
| Length tolerance | 3 m plus or minus 1.5 mm |
| Collecting table length | 6 m |
| PLC brand | Delta |
| Feed width adjustment | Manual |
| Punching die | Adjustable |
| Control system language | Chinese and English or on request |
Customization Options
Industrial voltage standards differ across countries and regions. The standard configuration of this warehouse shelves storage racks making machine is 380V 50Hz 3 phase, and it can also be customized to the customer's local voltage. Electrical components are selected for the corresponding voltage.
The control system language supports Chinese and English. If the customer needs another language interface, this warehouse shelves storage racks making machine can also be customized on request.
This equipment can produce two different sizes, and switching is done by setting parameters on the PLC. Customers can select saved size specifications from the screen.
Not all parameters are customizable. Standard configuration, optional configuration, and custom solutions that require customer confirmation are three different categories. The specific customization plan needs to be discussed with a professional.
Warranty and Technical Support
This warehouse shelves storage racks making machine comes with a 1 year warranty.
For technical support, we provide remote video guidance for installation and commissioning. Customers can also send staff to our factory for on site operator training.
A set of free spare parts comes with the machine, including: travel switch, fuse, relay, encoder, operation manual, maintenance tools, and circuit diagram.
Whether installation and commissioning are included in the standard package, and conditions for engineer dispatch, need to be confirmed separately based on the customer's location and actual requirements.
Different voltage standards, different customer profiles, and different output targets all affect whether the machine can match. These are core questions to confirm at purchase. When evaluating a warehouse shelves storage racks making machine, customization capability and after sales support are two areas to confirm. Bring your product specifications, material thickness, voltage conditions, and output targets, and we will help confirm the configuration plan and clarify the details of after sales support.
