Fully Automatic Slitting Machine Line: Hydraulic Coil Slitting Machine for High-Speed Metal Cutting
As a pivotal hub bridging upstream and downstream segments, the Hydraulic Slitting Line seamlessly connects massive master coils with specific narrow-strip requirements. Functioning as a versatile metal slitting line machine and coil slitting line machine, it serves the critical needs of precision manufacturing sectors.
Contact: Elliot liu
Email: [email protected]
WhatsApp: 008615127728988
Detailed Content
As a pivotal hub bridging upstream and downstream segments, theHydraulic Slitting Lineseamlessly connects massive master coils with specific narrow-strip requirements. Functioning as a versatilemetal slitting line machineandcoil slitting line machine, it serves the critical needs of precision manufacturing sectors.
Leveraging advantages like high speed and low energy consumption, thishigh speed slitting machinelinetransforms wide coils into standardized strips with smooth edges. Operating as afully automatic slitting machine linefor efficientslitting line cutting, it guarantees high-quality raw materials for industries such as automotive, power generation, and home appliances.
Main technical parameters
1.Steel Coil Parameters
| Material | CRS and GI |
| Tensile strength | δb≤450Mpa δS≤260Mpa |
| Steel thickness | 0.3-3.5mm |
| Steel width | 500-1600mm |
| Steel coil I.D | φ480-520 mm |
| Steel coil O.D | φ1600mm(max) |
| Steel coil weight | 15T(max) |
2.Slitter Parameters
| Knife pivot diameter | Ф220 mm |
| Knife pivot material | 40Cr |
| Blades specification | Φ220mmXφ340mmX15mm |
| Blade material | H13K |
3.Slit Parameter
| Max slit quantity | 5 pcs (3-3.5mm) 8 pcs (2mm) 15 pcs(1mm) 25 pcs(0.3mm) |
| Width precision | ≤±0.05mm |
4.Other Parameters
| Power | 380V/60Hz/3Ph |
| Line speed | 0-60m/min |
| Capacity | Around 220 Kw |
| Whole line Dimension | 23m(L)X8m(W) |
| Daily production capacity | Around 40T (for 8 hours) |
| Operator needed | 1 mechanical engineer ,2 common workers |
| Line direction | From right to left(Face to machine) |
💡 Why Choose OurHydraulic Slitting Line
- Theelectrical control systemlets you change thewhole line speedeasily and even feed the plate manually when needed.
- Ourrecoilerworks with the divided strips to make sure the coil is tight and even, with adjustabletensionandspeed.
- Theslitterhas aside guide deviceto stop the strip from jumping, helping you get accurate cuts for anystrip thickness.
- We check everything fromdesigntomanufacturingandservicescarefully before the machine leaves our factory.
